Processor

Intel® Core™ i5-13420H, 8C (4P + 4E) / 12T,   P-core 2.1 / 4.6GHz, E-core 1.5 / 3.4GHz, 12MB

Graphics

Integrated Intel® UHD Graphics

Chipset

Intel® SoC Platform

Memory

2x 8GB SO-DIMM DDR4-3200

Memory Slots

Two DDR4 SO-DIMM slots, dual-channel capable

Max Memory

Up to 32GB DDR4-3200

Storage

512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0

Storage Support

Up to two drives, 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB • M.2 SSD up to 1TB

Card Reader

No card reader

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek® ALC256 codec

Speakers

2Wx1

Microphone

No microphone

Power Supply

65W 89% Adapter

DESIGN

Keyboard

USB Calliope Keyboard, Black, English

Mouse

USB Calliope Mouse, Black

Optional Bay

None

Expansion Slots

Two M.2 slots (one for WLAN, one for SSD)

Case Color

Black

System Fan

1x System Fan

Stand

None

Adapter Cage

None

Toolless Chassis Screw

None

Mounting

None

Pen

Pen Not Supported

Form Factor

Tiny (1L)

Dimensions (WxDxH)

179 x 182.9 x 36.5 mm (7.05 x 7.2 x 1.44 inches)

Weight

Around 1.11 kg (2.45 lbs)

CONNECTIVITY

Ethernet

Integrated 100/1000M

WLAN + Bluetooth

Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 + BT5.2

WWAN

Non-WWAN

Front Ports

1x USB-C® 3.2 Gen 2 (support data transfer and 5V@0.9A charging)

1x USB 3.2 Gen 2 (Always On and 5V@2.1A charging)

1x headphone / microphone combo jack (3.5mm)

Rear Ports

2x USB 2.0

2x USB 3.2 Gen 2

1x HDMI® 2.1 TMDS

1x DisplayPort™ 1.4

1x Ethernet (RJ-45)

Monitor Cable

None

SECURITY & PRIVACY

Security Chip

Firmware TPM 2.0 integrated in SoC

Physical Locks

Kensington® Security Slot™, 3 x 7 mm

Chassis Intrusion Switch

Chassis Intrusion Switch

MANAGEABILITY

System Management

Non-vPro®

CERTIFICATIONS

Green Certifications

ENERGY STAR® 8.0

EPEAT™ Gold Registered

ErP Lot 3/7

RoHS compliant

TCO Certified 9.0

SOFTWARE

Operating System

Windows® 11 Pro, English

Bundled Software

None
